12-stage reactive power controller RGM-12S - TENSE
Description
The RGM-12S is designed to compensate for the inductive component of the reactive power generated by electric motors, machine tools, compressors, air conditioners, pumps and fans.
It can compensate for up to 3000 kVA of reactive power.
Advantages
-
12 stages for more precise compensation and longer capacitor bank lifespan
-
Time delay setting for power-on, power-off, and restart steps
-
Output relays for indicating compensation errors and limit exceedances (THD-V, THD-I)
-
Separate relay for fan
-
Setting the target cosφ and the permissible fluctuation for stable operation
-
Automatic measurement of capacitor parameters for the current system status
-
Option to block unauthorized access to the settings
-
Large LED display with:
-
Current cosφ
-
Current and voltage
-
Mains frequency
-
Active power, reactive power and apparent power
-
Total harmonic distortion (THD) for current and voltage
-
Stage status and fan mode
-
-
Automatic and manual compensation options
-
The display works at low temperatures down to -20 °C
Technical parameters
| parameter | Value |
|---|---|
| Supply voltage | 100 - 300 V AC |
| Network frequency | 50/60 Hz |
| Power consumption | <10 VA |
| Temperature range | -20 ... +55 °C |
| Maximum humidity | 90% (non-condensing) |
| Voltage measurement range | 10 - 300 V AC |
| Current measurement range | 10 mA - 5.5 A (without current transformer) |
| Connectable TTI | 5/5 A ... 9995/5 A |
| Measuring range cosφ | ±0.000 - 1.000 |
| Measurement accuracy | Voltage/Current - 1%, cosφ - 1%, Active Power/Power - 2% |
| Advertisement | 4-digit LED, digit height 20 mm + information LEDs |
| Step output contacts | 3 A / 250 V AC |
| Fan and alarm outputs | 3 A / 250 V AC |
| Number of levels | 12 |
| Cable diameter | 1.5 mm² (steps and relays), 2.5 mm² (TTI) |
| Installation | Flush-mounted installation |
| Maximum height | <2000 m |
| Protection class | IP41 (front panel), IP20 (housing) |
| Dimensions of the switchboard cutout | 140 × 140 mm |
| Weight | max. 900 g |
functions
-
Clear LED display for monitoring all stages and network parameters
-
Automatic and manual reactive power compensation
-
System protection and extended capacitor lifespan
-
Accurate measurement and display of all important network parameters
