Klimaanlage für Schalttafeln / Cooler 2100W, PAD2100.01, Plastim
- Regular price
- €2.284,96
- Regular price
-
- Sale price
- €2.284,96
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
Pre-order product
- Description
- Instructions
- Payment methods
- Warranty
"Design Series" Klimagerät für Schaltschränke / Kühler 2500 Watt / 8550BTU für Schaltschränke und Automatisierungsschränke zur Seiten- oder Wandmontage.
Das Klimagerät PAD2550.01 (PLASTIM) für Schalttafeln ist mit dem hochmodernen offenen Rotationskompressor von HIGHLY, einem Dixell-Thermostat, einem Kondensatverdampfer und einem Endschalter zur Steuerung der Schaltschranktüröffnung ausgestattet.
Alles, was für die Installation der Klimaanlage für den Schaltschrank benötigt wird, ist im Lieferumfang enthalten - Dichtungen, Abflussrohr, Befestigungsschrauben, Stromanschluss.
|
TECHNISCHE DATEN |
PAD2100.01 |
|
Kühlleistung L35 / L35 |
2100W / 7200BTU |
|
Betriebsspannung |
230VAC |
|
Frequenz |
50/60 Hz |
|
Anlaufstrom |
10A |
|
Betriebsstrom |
3.8A |
|
Sicherung |
16A |
|
Leistungsaufnahme |
800W |
|
Betriebsbereich |
0-55 °C |
|
Thermostat Werkseinstellung |
35 °C |
|
Abweichung |
4 °C |
|
Max. Luftmenge Interner Kreislauf |
510 m³/h |
|
Max. Luftmenge externer Kreislauf |
625 m³/h |
|
Typ des Kältemittels |
R134a |
|
Menge des Kältemittels |
700gr |
|
Abmessungen |
980x430x270mm |
|
Gewicht |
46kg |
|
Schallpegel |
80dB |
|
Schutzgrad (interner Kreislauf) |
IP 54 |
|
Schutzart (externer Stromkreis) |
IP 34 |
|
Farbe |
RAL7035 |
|
Kompressor |
HIGHLY/HITACHI |
|
Verdichter Typ |
Rotierend |
|
Ventilatoren |
EBMPAPST |
|
Montageart |
Wandmontage |
