RS485/RS232 to USB - USB-CON protocol converter (TENSE, Türkiye)
USB-CON is a compact converter/gateway for connecting RS485/RS232 (MODBUS) devices to a computer via the USB port . It enables the quick connection of power meters, multimeters, network analyzers, and other automation devices in industrial and home applications.
Features and benefits
-
Direct PC ↔ RS485/RS232 (MODBUS) connection
-
No separate power supply required - the converter is powered via USB.
-
Compact dimensions: 9 × 6 × 3 cm
-
Quick connection via terminal block
-
USB cable (1.2 m) included in the package
-
Support for up to 256 devices on the RS485 bus
-
LED indicator for power supply and communication
-
High bitrate of up to 203,400 bps
-
Galvanically isolated inputs and outputs
-
Wide temperature range: -20...+55 °C
-
Free software for configuration and diagnostics
Technical parameters
-
Interface: USB ↔ RS485 / RS232
-
Protocol: Modbus (RTU/ASCII)
-
Power supply: via USB port
-
Maximum communication speed: 203,400 bits/s
-
Maximum number of devices on the RS485 bus: 256
-
Display: LED - Power / Data
-
Dimensions: 90 × 60 × 30 mm
-
Operating temperature: -20...+55 °C
