Network analyzer panel: current, voltage, frequency, power, energy, RS485
- Regular price
- €148,80
- Regular price
-
- Sale price
- €148,80
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
- Description
- Instructions
- Payment methods
- Warranty
3-phase network analyzer / network analyzer / network analyzer - Multifunction digital panel meter, current, voltage, frequency and total power display, with relay output, RS485 Modbus RTU - TPM-04SHDL Manufacturer TENSE (Turkey) Panel Meter.
Power analyzers are designed for measuring and monitoring electrical values. Thanks to their communication function, measured energy values can be monitored and reported independently. These analyzers can be used to perform analyses such as power quality, efficiency, and unit cost calculations.
Key advantages:
- RS485 Modbus RTU (1200-19200b/s)
- Three-phase voltage transformer and three-phase current transformer.
Shows the harmonic components of voltage and current up to the 31st.
Display of active power per phase (P)
-
Display of reactive power per phase (Q, inductive and capacitive)
Display of apparent power per phase (S)
Display of the cosφ and power factor values for each phase.
Display of voltage (V) and current (I) values between the phases and the neutral phases and measurement of the frequency.
Display of total imported and exported active energy values (ΣkWh)
Display of the total values of inductive and capacitive reactive energy (ΣkVArh).
Display of minimum and maximum values, max.
2 relay outputs, 1 digital input
Event logs (high/low voltage/current, voltage/current asymmetry, THD-I)
The menu is password protected.
This network analyzer is typically used with current transformers – 60/5, 75/5, 100/5, 150/5, 200/5, 250/5, 300/5, 400/5, 500/5, 600/5, 800/5, 1000/5, 1500/5, or similar. If you wish to connect the analyzer to Modbus, we will gladly send you a Modbus address registration table upon request.
