ONKA 6mm2 screw terminal block DIN rail terminal 2-wire gray, 1010032
- Regular price
- €0,72
- Regular price
-
- Sale price
- €0,72
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
- Description
- Payment methods
- Warranty
Screw busbar connector / DIN rail terminal 2-wire gray, ONKA, made in Turkey
The compact ONKA installation rail connectors offer a wide range of options for connecting any cable with different cross-sections. The transparent housing allows for easy verification of the correct arrangement of the wires. The original ONKA quick-connect couplings offer a high level of installation convenience and 100% connection reliability.
Technical parameters
Cross-section of the connected single cable up to: 6mm2
Color: gray
Insulating material of the main housing: Polyamide (PA6.6)
Material contact/bridge: CK45 steel/copper
Tightening torque: 0.8 Nm
Connection position: side
Length of the cable tie: 12mm
Electrical connection type: screw terminal
Rated voltage: 750V
Rated current: 41A
Operating temperature range: -40°C
Operating temperature range up to: 140°C
Mounting type: DIN 35 mm mounting rail
Standard: EN-60947-7-1
