ONKA current transformer - CURRENT TRANSFORMER 125/5A, 44/20 (31), CLASS 1, 2.5VA (CK201255103 / 80010993)
- Regular price
- €12,32
- Regular price
-
- Sale price
- €12,32
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
Pre-order product
- Description
- Payment methods
- Warranty
Plug-in measuring transducers for primary rated currents 125 A, secondary current 5 A, rated power 2.5 VA, available in accuracy class 0.5S, ONKA.
The ONKA CK201255103 / 80010993 is a reliable clip-on current transformer designed for the indirect measurement of sinusoidal alternating current in residential, commercial, and light industrial electrical installations. It enables the safe conversion of a primary current of 125 A to a standard secondary current of 5 A , which is compatible with most measuring instruments.
Technical data
Basic parameters
-
Primary rated current: 125 A
-
Secondary current: 5 A
-
Rated power: 2.5 VA
-
Accuracy class: 1
Installation:
-
Mounting type: Slide-on design
-
Mounting feet: included in delivery
-
Installation without interrupting the power supply - ideal for quick installation in racks
Description
The transformer is designed for use in standard measuring and monitoring circuits where a current of 125 A needs to be converted into a safe current of 5 A:
-
Meters and electricity meters
-
Monitoring and control systems
-
Protection and automation circuits
It is suitable for simple meters, power monitoring and load control.
Advantages
-
Compact, slide-on design - very easy installation without disconnecting cables
-
Standard 5 A secondary current - wide compatibility with measuring instruments
-
Suitable for currents up to 125 A - ideal for household, commercial and light industrial applications
-
Rated power of 2.5 VA - sufficient for common measurement and billing tasks
Application
-
Switchgear for households and businesses
-
Electricity metering and consumption monitoring systems
-
Load control and monitoring
-
Connection of electricity meters, power meters, protection systems and automation
