ONKA current transformer - CURRENT TRANSFORMER 2000/5A, 125MM, CLASS 0.5S, 30VA (DK12520005312 - 80011780)
- Regular price
- €57,92
- Regular price
-
- Sale price
- €57,92
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
- Description
- Payment methods
- Warranty
Plug-in measuring transducers for primary rated currents 2000 A, secondary current 5 A, rated power 30 VA, available in accuracy class 0.5S, ONKA.
The ONKA DK12520005312 is a high-quality clip-on current transformer for the indirect measurement of sinusoidal alternating current in industrial, commercial and distribution systems.
Technical parameters
| parameter | Value |
|---|---|
| Primary rated current | 2000 A |
| Secondary current | 5 A |
| Inner diameter / busbar mounting | 125 mm |
| Rated power | 30 VA |
| Accuracy class | 0.5S |
| Mounting type | Plug-in / Slide-in (with mounting feet included) |
| Application | Indirect current measurement, monitoring, protection and load control |
Product description
The converter transforms a primary current of up to 2000 A into a secondary current of 5 A , thus enabling safe and reliable connections:
-
Measuring instruments and current meters
-
Protection and automation systems
-
Monitoring and control devices
With an accuracy class of 0.5S, it delivers stable and accurate data suitable for commercial measurements, power monitoring, and phase balancing .
It is installed on a 125 mm busbar without interrupting the main circuit, allowing for quick and convenient installation in switchboards and control cabinets.
Advantages
-
Primary current up to 2000 A - suitable for high-power networks and loads
-
Secondary current 5 A - compatible with most measuring and control devices
-
Accuracy class 0.5S - reliable and accurate measurements
-
Rated power 30 VA - ensures stable operation of the secondary circuit
-
Easy installation - sliding/window cover with mounting feet
-
Versatile use - suitable for switchgear, industry, commerce and measuring systems
Recommended use
-
Industrial and commercial switchgear
-
Energy monitoring and load control
-
Connection of electricity meters, counters, protection and automation systems
-
Phase balancing and current measurement in distribution and high-current networks
