ONKA current transformer - CURRENT TRANSFORMER 4000/5A, 125MM, CLASS 0.5S, 30VA (DK12540005312 / 80011783)
- Regular price
- €106,92
- Regular price
-
- Sale price
- €106,92
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
- Description
- Payment methods
- Warranty
Plug-in measuring transducers for primary rated currents 4000 A, secondary current 5 A, rated power 30 VA, available in accuracy class 0.5S, ONKA .
The ONKA DK12540005312 is a clip-on current transformer for the indirect measurement of sinusoidal alternating current . It is suitable for high-performance industrial and commercial switchgear , distribution systems, and measurement applications.
Technical parameters
| parameter | Value |
|---|---|
| Primary rated current | 4000 A |
| Secondary current | 5 A |
| Mounting/inner busbar diameter | Ø 125 mm |
| Rated power (secondary load) | 30 VA |
| Accuracy class | 0.5S |
| Mounting type | Window/plug-in mounting, including mounting feet |
Product description
The transformer converts a very high primary current (up to 4000 A) into a standard secondary current of 5 A , thus enabling safe connections:
-
Measuring devices and electricity meters
-
Protection and automation systems
-
Monitoring and measuring devices
Installation is carried out by sliding it onto the busbar and thanks to the supplied mounting feet, the main circuit does not need to be interrupted.
Advantages
-
High current carrying capacity - up to 4000 A primary current
-
Standard output 5 A - compatible with most measuring and monitoring devices
-
Accuracy class 0.5S - stable and accurate measurements, suitable for industrial and commercial applications
-
Rated power of 30 VA - sufficient for supplying a secondary circuit
-
Easy installation - window/removable cover + mounting feet
-
Versatility - suitable for switchgear, industrial plants, measuring, protection and automation systems
Recommended use
-
Large industrial switchgear and distribution systems
-
Industrial power grids and heavy-duty installations
-
Commercial and municipal electricity metering systems
-
Automation, control and protection systems, phase balancing and overload protection
